CHAIN FEEDING DOUBLE SURFACE PLANER

Spiked chain associated with four table rollers provides superior feeding capability for all types of wood.

Enhancing your production rate and quality with its superior feeding and planing capability
for all types of wood.

Table With Small Workpiece Feeding Device

The table surface is chrome coated for extra wear resistance at high speeds. Small workpiece feeding device (optional) is available.

Hold-Down Pressure & Feed Speed Control

Adjust the hold-down pressure and feed speed instantly and accurately according to the production needs.

Cutter Head Sliding Rack

The cutter head is mounted on rack for easy removal, quick replacement, and servicing.

Digital thickness adjustment

Direct scale-reading in inch and mm / Simple and clear command panel, with digital input of the working thickness

DSP-516S can process short workpieces, with air pressure control and detachable guide fences. Minimum working thickness is 15mm using detachable guide fences.

Model		DSP-516	DSP-516S	DSP-524
Max width of cutting	mm	405	405	610
Max thickness of cutting	mm	170	170	200
Min. thickness of cutting	mm	8	15	10
Min. length of cutting	mm	250	100*	310
Top spindle speed	rpm	rpm 4000
Bottom spindle speed	rpm	rpm 4000
Feed speed (variable)	M/min	8-24
Dust hood outlet dimension	mm	125	125	150
Table area (LxW)	mm	480x2180	480x2180	685x2615
Top cutterhead drive motor	hp	15	10	15
Bottom cutterhead drive motor	hp	10	7.5	10
Feed drive motor	hp	2	2	3
Pressure roller elevation motor	hp	1/2	1/2	1/2

*DSP-516S can do short workpieces processing, with air pressure system and detachable guide fences,
Min.working thickness will be 15mm while with detachable guide fences.
